Cta-2006 Compliant

Number of Channels

4

Total Power (Sum of Rated Power)

600 Watts

Rated Power (RMS Continuous Power)

75 Watts x 4 @ 4-Ohm 150 Watts x 4 @ 2-Ohm 300 Watts x 2 @ 4-Ohm Bridged

Dynamic Power (PVC/PowerCube®)

129 Watts x 4 @ 4-Ohms 0° Res 211 Watts x 4 @ 2-Ohms 0° Res

Bridgeable

Yes

Frequency Response

20Hz to 20kHz +/- 1.0dB

Input Sensitivity

150 mV - 12 V

Circuit Topology Class

Class A/B

Efficiency (average)

68% @ 4-Ohm

Total Harmonic Distortion (THD+Noise)

4-Ohm: <1.0% 2-Ohm: <1.0%

Signal Input

Hi/Low level: 2 RCA pair

Signal Output

Low level: 1 RCA pair

Tone Controls

Front Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or Front Punch EQ2 Treble: 0dB to +12.5dB @ 12kHz Rear Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or Rear Punch EQ2 Treble: 0dB to +12.5dB @ 12kHz Function depends upon LP/AP/HP switch position

Crossover Controls

Front/Rear High-Pass (HP): 50Hz-250Hz @ 12dB/octave Butterworth Front/Rear Low-Pass (HP): 50Hz-250Hz 12dB/octave Butterworth All-Pass: Yes

Remote Controls

Optional Punch Level Control (PLC2) Ready

Visual Indicators

Power/Protect/Thermal LED Input Clip LED3 Output Clip LED1,2,3 LED Color Legend: 1BLUE: <0.5% THD 2VIOLET: 1% THD 3RED: 10%+ THD

Power Wire Gauge

4 AWG

Power Input Connector

Captive C-Clamp

Speaker Wire Gauge

8 AWG to 18 AWG

Speaker Output Connector

Captive C-Clamp

Cooling

Convection

Heatsink

Operating Voltage

9 - 16 VDC

Recommended Fuse (not included)

100 A

Average Current Draw (13.8V Music)

45 A

Max. Current Draw (13.8V Sinewave)

90 A

Suggested Alternator

75 A

Included In The Box

Dimensions (H x W x D)

2.38 x 7.76 x 13.28 (in) 6.05 x 19.71 x 33.73 (cm)

Shipping Weight

12.8 Lbs. (5.80 Kg.)
